• V60 the 2

    RGB

    Hot-Swappable

    16.8 million colors RGB

  •

    FEATURE

    RGB Backlight

    18 RGB Mode pre-installed

    16.8 million colors RGB

    PBT Double Shot Keycap

    Backlight seamless keycap

    Hot-Swappable

    Easily remove and install any MX-based switch

    Customizable layouts

    KBP60THE2 driver

  • broken image

    Kuro Black / Shiroi white

    LED Backlighting – RGB LED lights with 18 pre-installed effects and driver download for user-defined effect. Variable animation speeds and brightness settings. 16.8 million colors RGB

  • broken image

    seamless PBT Double shot keycap

    Enjoy durability without cramping your style. Made from doubleshot PBT, these keycaps are thicker and sturdier, and won’t wear down to a shiny finish. They also showcase the sleekest, thinnest font ever seen on a PBT keycap for a clean, minimal aesthetic that will never fade.

    Made of high-grade thermoplastic with a sturdy, textured finish that never wears out, the keycaps are crafted with extra-thick walls fit for intensive gaming that produce satisfying, solid keystrokes

  • broken image

    Hot swap rgb pcb desogn

    Easily remove and install any MX-based switch without any soldering. Personalize to what works for you, and use any combinations of switches!

  • How to remove the switches

    • When removing the switches, use the switch puller. Unclip the top and bottom clips while pulling up gently.
    • The low profile switches are more difficult to remove. When removing them, make sure you clip the sides.
    • Be careful not to scratch the keyboard with the puller.
    • BE VERY CAREFUL when mounting the switches! If you feel a lot of resistance, don’t continue pushing. If you push too hard, you could break an electronic component and void the warranty.
    • When mounting the switches, align the pins and insert them into the correct holes. The same applies to the low profile switches.
    • Be careful not to bend the metal pins when mounting the switches.
    • While fitting the switches, do it gently. If you feel a lot of resistance, don’t continue pushing. If you push too hard you could break an electronic component and void the warranty.
    • The hole on the switch where the LED light shines through should be at the top.

  • broken image

    Detachable USB-C CONNECTION

    The swappable connector PCB allows switching from USB-C to Micro USB with no soldering necessary.

    Detachable Cable for Enhanced Portability

    This convenient feature allows you to remove the cable when traveling with your keyboard, protecting both the keyboard and the cable and improving its portability.

  • broken image

    Engine

    ARM Cotex-m0 32bit mcu

    Say goodbye to rage quits due to crappy hardware. V60THE2 comes equipped with a 32-bit ARM Cotex-M0 32Bit processor for consistent precision and performance. Register keystrokes instantly. Save and execute commands and macros in a snap.

  • broken image

    engine

    Customize V60 the2

    RGB / Button / Macro Setting

    Not support MAC OS

  • broken image

    standard ansi layout

    Standard 60% keyboard and meet all your needs!

  •



                                                                                                              beautiful rear

    The end of the Tōkaidō: arriving at Kyoto

    The Fifty-three Stations of the Tōkaidō

    Utagawa Hiroshige

  • broken image

    N-KEY ROLLOVER

    V60THE2 uses N-key rollover technology that results in the most efficient, accurate anti-ghosting technology yet. N-key rollover ensures that every single keypress is correctly detected, even during your most heated, button-mashiest moments - or your chaotic crunch-time coding situations.

  • broken image

    special feature

    Arrow mode : lock right corner as arrow keys!

    Mac mode : swift alt as Command key!

    Default Setting : clean all memory and back to original status!

  • V60THE2 review

    Review in Spanish

    RGB Backliting Test

    broken image

    Review in French

    http://www.macfay-hardware.fr/

  • accessories

    1 x1.25 command keycap

    Wire keypuller

    switch puller



    BONUS

    Random 18~24pcs rainbow keycaps













  • You decide how it should feel

    Choose the mechanical switches that fit your needs.

    broken image

    Cherry series

    MX Brown / Red / Silver

    broken image

    Kailh series

    Box White / Brown / Burnt Orange / Dark Yellow

    Jade / Navy

    Speed Cooper / Bronze / Silver

    Silent Pink / Brown

    broken image

    Gateron series

    Brown / Red / Yellow / Clear / Green

  • firmware update

    version : V0103

    Date : 2021/02/22

  • Description

    KBParadise V60THE2 MECHANICAL KEYBOARD

    COMPACT SIZE CUSTOMIZED WITH SEAMLESS PBT DOUBLE SHOT KEYCAPS

    Trying out different switches, replacing old ones, and matching several types of mechanical keyboard switches used to be difficult and required advanced technical skill. The KBParadise V60THE2 is the mechanical keyboard featuring hot-swappable switches for Cherry, Gateron, and Kailh branded switches.

    Armed with a V60THE2, 100% anti-ghosting (full NRKO), LED back lighting (several modes), modular switches, seamless PBT double shot injection keycaps, and minimalistic design –V60THE2 is revolutionizing the mechanical keyboard market, giving users full control without needing any technical experience.

    Features

    • Hot-swappable switches. Easily remove and install any MX-based switch without any soldering. Personalize to what works for you, and use any combinations of switches!
    • LED Backlighting – RGB LED lights with 18 pre-installed effects and 1 slot for user-defined effect. Variable animation speeds and brightness settings.
    • Easy Access Hot-Keys – Directly access shortcuts to productivity, internet and multimedia functions
    • Raised Keys, Minimalist design – No visible branding on keyboard to make your battlestation look clean as possible. Raised key design allows you to easily clean your keyboard.

    Specifications:

    • Model: KBPV60T2
    • Prebuilt :  Yes
    • Mechanical Switch: Cherry / Kailh / Gateron
    • Keycaps color: white or black
    • Top color: white plate
    • Bottom color: white or black ABS plastic plate
    • USB cable color: white or black
    • Keycaps: PBT Seamless Double shot
    • Removable USB-C
    • Stabilizers Included
    • 61 Key Standard QWERTY layout (ANSI)
    • 100% Anti-Ghosting
    • N-Key Rollover: Full NKRO via USB, or 6KRO
    • Polling Rate: 1000 Hz
    • Backlight: 16.8 million colors RGB
    • Dimensions (L x W x H) 290 × 100 × 40 mm (11.4 × 4.0 × 1­.6 inches)

    SYSTEM REQUIREMENTS:

    • Interface: USB 2.0
    • Windows XP, Vista, 7, 8, 10 or Mac OS or Linux (Hotkey+Software functions only work on Windows)

    INCLUDED IN BOX:

    • V60THE2 keyboard
    • Manual / Quick Start Guide
    • Keycap Puller Tool
    • Switch Puller Tool
    • 24pcs rainbow 1x1 keycap



  • Q & A

    find the info you need here!

    Q : What is the difference between V60 , V60 Type R and V60 THE2

    • V60 : design in 2014 and discontinue in Dec., 2020
    • V60Type R : Open source firmware. Support TMK and QMK. If you are familiar with QMK to re-map layout, V60Type R might be your best choose.  2 options,Type R standard model not offer any backlit, pure typing. Keycaps coule be in ABS Black or ABS Double Shot ( Deep Ocean or Purple Dream ) Type R Polestar with shine through keycap , offer front White LED and rear RGB underglow backlit. And Type R Polestar with ABS double shot keycap. Front in Deep Ocean or Purple Dream keycap , no top LED. But with rear RGB Underglow.
    • V60 THE2 : on market in Feb. , 2021. The newest models.   18 RGB mode , Hot sawp switch , Seamless PCB Double Shot Keycap , program and setting through driver download.

    Q : on the v60 the2 will I be able to set caps lock as my function key?

    A : Our first edition driver for V60THE2 can program include Light , Button , Macro , but not include FN position. We start to upgrade Driver to adjust FN position. We will upload the newest driver on web-site once it ready.

    Q : V60 The 2, would it be possible to swap the case of the keyboard? If so, would it be compatible with other cases?

    A : you can open the V60THE2 case easliy. There are 4 screws at back side of case. Our V60THE2 PCB can fit on other 60% case ( Poker series ). There are a screw hole at right and left side on PCB.

    But our V60THE2 case is smaller than other 60% case , so the case not able to fit on other 60% PCB.

    Q : Whenever I click the left ALT button, it activates the WINDOWS button. and whenever I click the WINDOWS button, the ALT button activates

    A : It should be lock on Arrow mode or Mac mode.

    Please press FN+ left shift and then press "enter".

    It will back to default setting.

  • where to buy?

    USA / Canada

    USA : https://mechanicalkeyboards.com/

    Europe

    UK : http://www.keyboardco.com/

    Nordic : https://www.maxgaming.com/
