How To Use VIA To Program Your Keyboard

broken image

How to Remap a Key on VIA?

1. Download and install the VIA for your operating system (click upper picture to download).

2. Connect your keyboard with our cable and open the VIA.

3. Please download the correct keymap JSON file when you see “Searching for devices…” on the VIA's Configure tab. Since it takes time for Github to approve our VIA code submission, some keymap JSON files may not be automatically recognized at the moment.

You can download the keymap JSON file by searching “keymap working on VIA” on the keyboard product page.

4. Once you downloaded the keymap JSON file, please go to the VIA, and turn on "Show Design tab" in the "Settings" tab.

5. Drag the JSON file into the “Design” tab on the VIA.

6. On the Configure tab, select the KEYMAP section, and click on the key that you want to program, and the key will then flash slowly. Click on a key you want to remap in the BASIC/MEDIA/MACRO/LAYERS/SPECIAL/QMK LIGHTING/CUSTOM section. And it's done. Here is a video example.

How to create a macro on VIA?

A macro is a series of keys pressed together to perform an action, now, you can program to just use one key to perform the same action, for example, holding Shift+Command+4 (screenshot on macOS) can be done with just one key. Here is how:

1. Go to MACROS on the top left corner of the Configure tab.

2. Search the keycodes that represent the key you want at, then, copy and paste the Aliases on the page onto the VIA.

3. For example, enter {KC_LSFT,KC_LGUI,KC_4} in the Macro 0 box area, and press Save. The M0 key will become Shift+Command+4 (screenshot on macOS).

4. Select the KEYMAP section, click on the key that you want to replace, and the key will then flash slowly on VIA. Go to the MACRO section on the lower-left corner, click the M0 key, and it’s done.


How to Use Different Layers to Set the Combination Keys

You can customize each key on each layer of your keyboard with VIA, there are two layers for Mac, and two layers for Windows. For example, the Q1 keyboard comes with 81 keys, so you can remap up to 324 keys (81 x 4) you want.


The default layer for the keyboard is layer 0.

The button M0(3) = layer 3

Example: Use the layer function in VIA to set power button = fn + INS on macOS.

1. We have the "fn" key (aka MO(1) on VIA). Now we need to set the power button = "fn" + "upper right corner key".

2. Click LAYER 1.

4. Hold fn and the upper right key to power off your computer.

PS: The shutdown option will normally pop up and let you choose "Shut Down", "Sleep", or "Restart". However, please check if the system has the pop up option on just in case the system shuts down directly and the file is not saved.
